Gone are the days of manually winding the jockey wheel to raise or lower the caravan or trailer. The Black Jack Trailer Jack is the simplest, quietest and most advanced electric jack on the market today. The Black Jack Trailer Jack can come in three convenient options to suit your requirement:

BJTJ -1001 Includes clamp bracket, bolt kit,folding foot, foot pad, all weather cover, and wiring kit (hardwired back to Caravan house battery)

Kit Includes;
1x Black Jack Electric Trailer Jack
1x Black Jack Clamp Patented (part number BJTJ-BKT)
1x Black Jack Folding Foot (Part No. BJTJ-FF)
1x Black Jack Foot Pad (Part No. BJTJ-FP)
1x Black Jack All Weather Cover (part number BJTJ-Cover)
1x Black Jack Harness (part number BJTJ-HAR)

SPECIFICATIONS

BLACK JACK TRAILER JACK KEY FEATURES:
1600 kg lifting capacity, more than enough muscle
Robust 58 mm outer post built for the toughest conditions (normal jockey wheels are only 48mm)
Massive 560 mm stroke that will lift the caravan clear of the tow vehicle hitch in any conditions
Built in level indicator to easily adjust the caravan level after you unhitch
Removable foot pad extension for travelling
Tough powder coated finish
Emergency crank handle included as an emergency back up
Built in night light for operating after hours
12 volt 28 amp DC power plugs directly to 12 volt battery
Free installation kit included, easy DIY Installation (with BJTJ – 1001)
Free all weather cover to keep the rain out
Total weight including Black Jack Clamp 17 kg

BLACK JACK CLAMP KEY FEATURES:
6 different chassis bolt hole positions so it fits any Caravan or trailer A-Frame in Australia (6 inch, 5 inch, 4 inch or 3 inch)
Multiple top hole positions so the Black Jack can be installed facing the front, the side or the rear of the Caravan or trailer. Your choice!
Panel recess so you can install over the top of existing wire fittings maximizing the options of where to install on the A-Frame.
Safety chain insert hole so you can hang safety chains on the Black Jack Clamp.
Upper support and a lower support brackets designed to eliminate any lateral movement that may be caused by uneven surfaces.
Easy bolt installation. No additional modifications, welding or tools are required.
Tough powder coated finish
Australian Patent Pending (No. 2020902039)
Registered Australian Design
Assembled in Australia supporting Australian Jobs

BLACK JACK FOLDING KEY FEATURES:
Diameter Foot Plate: 15.2cm x 11.5cm
Height: 25cm
Weight: 2.2kg
Maximum Load: 1,000kg

BLACK JACK TRAILER JACK FOOT PAD KEY FEATURES:
Diameter: 20cm
Height: 2.5cm
Weight: 800grams
Maximum Load: 1,000kg


BLACK JACK DIY HARNESS INCLUDES:
5 m Battery Cable (7.92mm2) (8 B&S)
Fuse Box
30 amp Inline Fuse
2 x 10-6 Fuse Lug Terminals
Cable Crimp Connector
10-8 Battery Lug Terminal
Heat Shrink
